CRAVOT CyberRack E2 PLUS Hitch Bike Rack, 2’’ Receiver, 200 LBS Capacity
E2 Plus Classic User Manual
E2 Plus Classic Specifications
| Model Name | CyberRack E2 PLUS |
| Color | Black |
| Weight | 66.8 lbs |
| Material | Aluminum & Steel |
| Bike Capacity | 2 |
| Load Capacity | 200 lbs |
| Compatibility | For 2" hitch size only |
| Max Wheelbase | 52’’ |
| Max Tire Width | 5’’ |
| Foldable | Yes |
| Tiltable | Yes |
| Ramp |
Foldable Ramp
(Can be stored in vehicle)
|
| Hitch Pin Lock | Included |
| Package Weight | 77.9 lbs |
| Package Dimensions | 54.7x18.7x9.1 in |
| Applicable Hitched Bike Types | Electric Bike / Regular Bike |
| Note | Not intended for use with mopeds, motorcycles, or 3-wheel bikes |
E2 Plus videos
See the E2 Plus in action. Classic has a foldable ramp; Evo has a built-in ramp.
Bike Position and Securing Points
The E2 Plus Classic supports a maximum wheelbase of 52 inches. Use the securing points shown in the installation instructions and check that each bike is held correctly before driving. Wheelbase alone does not confirm compatibility; also check tire fit, frame contact points, and vehicle clearance.
Unique and Innovative
CyberRack E2 Plus adopts Patented Front Wheel Cradle for stable Fixation. Fits tire widths from 2.5" to 5"
Reinforced Structure
Robust metal frame provide exceptional durability and strength.
Incorporate adjustable components to reduce any potential swaying during transit.
Check Rack Dimensions Before Ordering
Compare the rack dimensions with your bike and vehicle setup. Check the instructions for the selected version and confirm clearance before use.
Will the E2 Plus Classic fit your setup?
For Classic with a foldable ramp only. Check the selected version before ordering; this guide does not cover Evo.
| Bike capacity | Up to 2 bicycles |
|---|---|
| Combined bike load | 200 lb / 90.7 kg maximum |
| Hitch receiver | 2-inch only |
| Maximum tire width | 5 in; check complete fit |
| Loading ramp | Foldable ramp included |
| Foldable / tiltable | Yes / Yes |
- Unequal bike weights are allowed. Place the heavier bike closest to the vehicle and stay within the combined-load limit.
- Not compatible with RVs or bumper-mounted receivers.
- Confirm bike, vehicle and hitch compatibility before ordering.
Bike and vehicle fit
Check tire fit, wheelbase, mounting contact points and vehicle clearance against the matching instructions. A maximum tire width alone does not confirm compatibility. Follow the vehicle and hitch manufacturers’ load requirements.
Also excluded: recumbent bikes, tandem bikes, trikes or other three-wheel bikes, scooters, mopeds and motorcycles.
Adapters, hitch extenders, swing-away adapters and front hitches are not recommended because compatibility testing has not been completed. For cargo bikes, contact Support with basket position, dimensions and bike details before ordering.
Bike weight and loading order
For the E2 Plus Classic, the battery and accessories such as baskets, panniers, child seats, and locks may remain installed during transport, provided they are securely attached and do not interfere with mounting, straps, or vehicle clearance. Include everything left on each bike in its actual transport weight.
Keep the bikes within the 200 lb combined transport-load limit and place the heavier bike closest to the vehicle. The combined rating does not establish the maximum permitted weight for one bike. Confirm any per-bike and loading-position limits for your exact version before ordering, and complete all bike, rack, vehicle and hitch checks.
Frame contact points
For step-through and step-over bikes, the seat tube is the preferred upper contact point. The top tube is a secondary option for suitable non-carbon frames. For carbon-fiber frames, CRAVOT recommends seat-tube contact and advises against top-tube contact.
The bicycle manufacturer must permit clamping at the chosen contact points; this is not approval for every frame.
Installation, loading and manuals
Follow the complete rack and bicycle instructions; this overview does not replace the manual.
- Install directly into the 2-inch receiver and secure the hitch pin lock.
- Open and position the ramp, then load the heavier bike closest to the vehicle first.
- Secure the front wheel, rear wheel and seat or middle tube as shown in the manual.
- Check that both bikes are secure before driving. Recheck straps and bike position regularly on long trips, especially after rough road sections.
